Gold plating involves the deposition of a thin layer of gold onto the surface of a Gold Finger PCB. This is typically done to improve conductivity, corrosion resistance, and solderability. The gold layer acts as a protective barrier, preventing oxidation and ensuring a stable connection between components. PCBs can be gold plated through various methods, with electroplating being the most common.
